LCD splicing screen conference display screen security monitoring splicing screen
Quick detail:
1. High resolution, high contrast, Super Wide Viewing Angle, super narrow edge design, double side stitching only 0.88 mm.
2. using vertical LED backlight system, built-in stitching controller can realize image stitching display function
3. using 3d digital image processing kernel, monitor more details, image signal gain function, more stable and correct image control,
realize image true restoration, improve system dependability
4. complete signal interface, support CVBS, DisplayPort, HDMI, VGA, DVI input
5. support computer centralized control, the parameters of the splicing unit can be adjusted by computer
Features of the video wall screens
High Brightness compared with TV and PC LCD screen, DID LCD screen has higher brightness. TV OR PC LCD screen
brightness is only 250 ~ 300 CD/M2, and DID LCD screen brightness can reach 700 cd/m2 above. High contrast DID LCD
screens have 1200:1, or even 10,000:1 contrast, more than twice as high as traditional PC or TV LCD screens, and three times
as high as a rear projection. 3. Better color saturation at present, the color saturation of conventional CRT is only about 50% ,
while DIDLCD can reach 80%-92% of high color saturation, which benefits from the color calibration technology developed for DID products
Advertising lcd video wall Specification:
| Size | 55 inches 1021.98mm*576.57mm*125.2mm |
| Power input | AC 110V-240V 60/50HZ |
| Resoultion | 1920*1080 /3840×2160 |
| Pitch | 0.53025 mm×0.53025mm |
| View angel | 178*178H*V |
| Brightness | 500 cd/m2 |
| Contrast | 3000:1 |
| Response | 3s |
| Color | 16.7M |
| HDMI Imput | 1 |
| DVI imput | 1 |
| VGA import | 1 |
| RS232 RJ45 imput | 1 |
| RS232 DP RJ45 output | 1 |
| HDMI line | 1m |
| WLAN line | 1 |
| Bracket | Wall mounted floor standing on choice |
| Name | LCD splice screen |
