Desktop Install Wifi Digital Signage Face Recognition Body Ir Temperature Thermometers Measurement

Name: Desktop Install Wifi Digital Signage Face Recognition Body Ir Temperature Thermometers Measurement
Brand: Genevision
Price: 1 USD

China Desktop Install Wifi Digital Signage Face Recognition Body Ir Temperature Thermometers Measurement wholesale

Brand Name : Genevision

Model Number : MG-080D

Certification : CE FCC ROSH CCC

Place of Origin : China

MOQ : 1pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/Month

Delivery Time : 5-15 days

Packaging Details : Carton box with bubble first, then wooden case package

Function : Face Recognition Body Temperature Instrument

Face capacity : 10,000 faces(Android), 50,000 faces(Linux)

NPU(face recogntion algorithm) : Inbuilt Convolutional Neural Networks accelerator NPU，1.2T Hash rate

IR camera : 1/5" industrial low illumincance sensor

Infrared Temperature Sensor Type : Thermopile far-infrared sensor

Fever detection : 28-37.3℃(programmable)

Software : SDK support

Working temperature : -10℃~60℃

Storage temperature : -20℃~60℃

Error ranfe : ±0.3℃

Detection distance : 0.3M-1.2M

Contact Now

Table type 8inch LCD montoring Facial Recognition device Door Access Control system management

Face recognition Product Features
1.Supports P6S private protocol + ONVIF 2.6 protocol (downward compatible with ONVIF 2.4). Supports web interface, multiple parameters can be configured directly.
2.Supports intelligent body temperature monitoring, real-time display of synchronized temperature data over video; non-contact measurement of body temperature (0.3M--1.2M).
3. Supports AI Face Recognition and Comparison (0.3M-1.5M) based on Face++ AI algorithm, uses the recognition result to control the door opening action or prompt the voice alarm; support Wiggins protocol.
4. Supports mask recognition, use Face++ AI algorithm to accurately identify whether wearing a mask, and prompt voice announcements
5. synchronously. The recognition accuracy rate reaches 98%.
6. Supports configure network by RJ45 + WIFI hotspot; supports external RS485, USB, alarm I/O output, etc.
7. Supports stand-alone system for face recognition, mask recognition, intelligent temperature monitoring display and voice prompts.
8. Portrait database capacity is 10,000 faces.
9. Abnormal body temperature triggers display alarm/voice alarm/mobile APP alarm.
10. Anti-thunder, anti-surge protection, waterproofing grade IP66.

BodyTemperature Measurement
Multi-points, multiple temperature collection,correction algorithm and other technologies are used to measure the body temperature in real time. For the case of exceeding the set threshold, in addition to the screen display text, warning voice and other prompts, it can also push alarms to the user's mobile

Location	Indoor	Internal storage	8GB
CPU option 1	Linux, ARM Cortex A7 1GHz	Face capacity	10,000 faces(Android), 50,000 faces(Linux)
CPU option 2	Android, RK3288, 1.8GHz	Face recognition speed	0.5-1 second
NPU(face recogntion algorithm)	Inbuilt Convolutional Neural Networks accelerator NPU,1.2T Hash rate	Voice announcement	English,italy,france,spanish ect..
RAM	DDR3 512MB	Fever warning	Support
RGB camera	1/2.7" Industrial wide dynamic sensor	IR camera	1/5" industrial low illumincance sensor
	Purpose: Face recogntion		Purpose: Live detection
	Inbuilt chip: AR0230		Inbuilt chip: GC2145
	Resolution: 1920*1080		SOC image processor ISP
	1080P Real Video output		1080P Real Video output
	Dot dimension: 2.9um*2.9um		0.01Lux low illuminance with 850nm infrared LED, suitable for various of complex light condition
	SN ratio: 45dB		Resolution: 1616*1232
	Dynamic range: 115dB		Dot dimension: 1.75um*1.75um
	Lens structure: 650nm±10nm		SN ratio: 45dB
	Iris: 2.0		Dynamic range: TBD
	Focus length: 4.35mm		Lens structure: 850nm narrow bandth ±10nm
	FOV angle: D=65°H=59°V=38°		Iris: 2.8
	Deformation:<1%		Focus length: 2.8mm
	Lens combination: 4P+1IR		FOV angle: D=75°H=66°V=43°
	100dB wide dynamic range, suitable for complex light condition		Deformation: <1.5%
	30 frames/second		Lens combination: 4P+1IR
			30 frames/second
Infrared thermal imaging module	Sensor Type : Thermopile far-infrared sensor	Display	8 inches lcd monitors
	Purpose: Temperature detection	Display	Resolution: 800*1280
	Detection distance: 30-100cm	Image spin	0 , 90 , 180, 270 degree spin
	Temperature difference: ≤ ±0.2℃	Real time clock	Inbuilt clock IC, setup ON/OFF time
	Resolution: 32(H)x 32(V)(Linux)	Network	RJ45 port,100M ethernet
	Resolution: 16(H)x 4(V)(Android)		WIFI,support Wi-Fi 802.11b/g/n protocol
	Pixel Size : 90um		Hotspot
	Maximum Frame Rate :7~9Hz	Functions	Live detection
I/O port	USB OTG		With or without mask
	1 TTL, 1 RS232		Guest access control
	1 Relay output		Face similarity: 0-1
Audio	Inbuilt speaker at 2W 8Ω		Temperature compensation: 0-1000
Light compensation	Support white light, red LED compensation		Language: English, French(expandable)
Light compensation	Automatic or ON/OFF light compensation		Fever detection: 28-37.3℃(programmable)
SDK	Provided		Image import: USB or PC import
Case material	Aluminum CNC process, IP65	Consumption	12W(Max)
Power	DC12V(±10%)	Mounting type	Mounting or hanging, or by floor stand
Working temperature	-10℃~60℃	Dimension	421813cm
Storage temperature	-20℃~60℃	Weight	1.7 kg

Desktop Install Wifi Digital Signage Face Recognition Body Ir Temperature Thermometers Measurement
